Hardware and software design of control panels for the following types of textile machinery:
- Inspecting, measuring and rolling up fabrics on tubes
- Doubling measuring and rolling up fabrics on planks
- Packaging of finished rolls or cloth piles in polythene sheets
- Fabric rolls conveying and stocking systems
- Pattern cutting machines
- Rotating storages for loom beams, full and empty, or for heddles
- Beams rewinding machines
- Lines for felt inspection
- PC complete with LCD screen, keyboard, numeric pad for faults input
- Thermal or film transfer printer for printing piece quality certificate
- Laser printer for printing reports regarding statistics and orders management
- Electronic counter of meters to measure the fabric length
- Optical heads to measure the fabric height
- Electronic weighing unit
- Server, suitable in different configurations, to share data on local LAN and on Internet
Software package for data quality control “CHECKROLL” with following characteristics:
- Developed in VB, VB.net or ACCESS programming language
- O.S. Windows, Windows Server all versions
- Database SQL Server, Oracle all versions
- Clients, suppliers, articles database management
- Management of orders and technical documents specific for clients and type of fabric
- Information storage of faults input by the operators during fabric check and of automatic detected data regarding length, height and weight of fabric rolls
- Automatic classification of fabric quality, based on specific algorithms
- Automatic output of packing lists and shipping notes regarding checked goods
- Statistical reports regarding productiveness and faultness customised with data filters and different print layouts
- Connection with remote computer systems to share production data
Hardware Equipments
Software Packages
Computer system to filing and processing control quality data
Workstations installed on inspection machines and in the production office, composed with the following modules:
Labelling Machine
Hardware and software design of an automatic device for measuring length of fabrics, printing measure on a self-adhesive label and laying it down on the fabric selvedge each meter
- Electronic device suitable for any model of fabric inspection machinery
- Microprocessor unit to control all functions of the device
- Length measure detected by a bidirectional encoder , resolution 0.5 mm
- Thermal transfer printing of detected measure onto self-adhesive labels with big fonts for easy reading. Also barcode printing is possible
- Automatic laying of labels on fabric selvedge each meter. Correct positioning of labels is guaranteed by the automatic continuous centering of labelling head through a gear motor photocells controlled
- Membrane numeric keyboard and alphanumeric lcd display 4X32 characters for data reading and setting of all working parameters
- When the inspection machine is going backwards, the labelling device stops working then works again on forward motion when exact measure is reached for the following label
- Maximum working speed 80 mt/1’ for labels each meter
1
2
Hardware and software design and realization of an electronic system to monitor and radiocontrol a town aqueduct, optimization of wells water levels and pipes flow rates based on requests from users in different hours
Hardware Devices
- Monitoring PC connected by radiofrequency data transmission to a PLC network of system control
- Level and flow sensors
- Electrovalves for pumps motors driving
Software Packages
- Visual Basic for PC monitoring
- Microsoft Access for database management
- Specific software language for PLC
Hardware and software design and realization of a test station for rolled ball screws, with automatic detection of the rigidity value during application of variable loads to screw body
Hardware Devices
- Load cell to detect the axial load applied to the screw
- Two comparators to detect the warpage amount of the nut during changes of applied axial load
- Monitoring and control PC with multi I/O analogue/digital card
Software Packages
- S.O. Windows
- Visual Basic for system monitoring and control
- Microsoft Access for database management and reports printing
Hardware and software design and realization of a test station for rolled ball screws, by automatic detection of torque values during repeated working cycles of the screw
Hardware Devices
- Brushless motor inverter controlled to rotate the screw
- Load cell to detect torque values
- Monitoring and control PC with multi I/O analogue/digital card
Software PAckages
- S.O. Windows
- Visual Basic for system monitoring and control
- Microsoft Access for database management and reports printing
Hardware and software design and realization of an automatic nailing pallets system with machine auto learning through firstly a nailing cycle controlled by an operator
Hardware Devices
- nr. 3 nailing heads pneumatically driven for the operations of nails shot and two axis translation
- nr. 1 gear motor inverter controlled to move the belt carrying pallets
- nr. 1 multifunctional controller Elap Nexus to manage the whole system
TEXTILE MACHINERY
FABRIC QUALITY CONTROL CHECKROLL
LABELLING MACHINE
AQUEDUCT WELLS
MONITORING AND CONTROL
RIGIDITY MEASURE OF ROLLED
BALL SCREWS
TORQUE MEASURE OF ROLLED
BALL SCREWS
AUTOMATIC NAILING
PALLETS SYSTEM
